CPU:
- Intel Socket LGA4677 for Xeon W-3400 and W-2400 Series Processors
- Supports Intel Turbo Boost Max Technology 3.0
- Chipset:Intel W790 Chipset
Memory:
- 8 x DIMM slots, Max. 2048GB, DDR5 6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200(OC)/5000(OC)/4800 ECC Registered Memory
- Quad Channel Memory Architecture
- Supports Intel Extreme Memory Profile (XMP)
Expansion Slots:- Intel Xeon W-3400 and W-2400 Series Processors
- 5 x PCIe 5.0 x16 slot(s) (supports x16, x16, x16, x0/x8, x16/x8 modes)
Storage:
- Total supports 2 x M.2 slots, 4 x SATA 6Gb/s ports and 3 x SlimSAS ports
Intel W790 Chipset:
- M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
- M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
- SlimSAS_1 slot supports PCIe 3.0 x4 mode NVMe device
- SlimSAS_2 slot supports PCIe 4.0 x4 mode or up to 4 SATA devices via a transfer cable. The cable is perchased seperately.
- SlimSAS_3 slot supports PCIe 4.0 x4 mode NVMe device
- 4 x SATA 6Gb/s ports
Ethernet:
- 1 x Marvell AQtion 10Gb Ethernet
- 1 x Intel 2.5Gb Ethernet
- ASUS LANGuard
USB:
- Rear USB (Total 13 ports):
- 1 x USB 3.2 Gen 2x2 port(s) (1 x USB Type-C)
- 4 x USB 3.2 Gen 2 port(s) (4 x Type-A )
- 8 x USB 2.0 port(s) (8 x Type-A)
Front USB (Total 7 ports):
- 1 x USB 3.2 Gen 2x2 (supports USB Type-C)
- 1 x USB 3.2 Gen 1 header(s) support(s) 2 additional USB 3.2 Gen 1 ports
- 2 x USB 2.0 header(s) support(s) 4 additional USB 2.0 ports
Audio:
- Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC
- - Impedance sense for front and rear headphone outputs
- - Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
- - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
- - Supports up to 32-Bit/192 kHz playback
Audio Features:
- - Power pre-regulator reduces power input noise to ensure consistent performance
- - Rear optical S/PDIF out port
- - Premium audio capacitors
- - Dedicated audio PCB layers
- - Unique de-pop circuit
- Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1
- Surround Sound audio.
Back Panel I/O Ports:
- 1 x USB 3.2 Gen 2x2 port(s) (1 x USB Type-C)
- 4 x USB 3.2 Gen 2 port(s) (4 x Type-A)
- 8 x USB 2.0 port(s) (8 x Type-A)
- 1 x Marvell AQtion 10Gb Ethernet port
- 1 x Intel 2.5Gb Ethernet port
- 5 x Audio jacks
- 1 x Optical S/PDIF out port
- 1 x BIOS FlashBack button
- 1 x Clear CMOS button
Internal I/O Connectors:
Fan and Cooling related:
- 1 x 4-pin CPU Fan header(s)
- 1 x 4-pin CPU OPT Fan header(s)
- 5 x 4-pin Chassis Fan header(s)
- 1 x W_PUMP+ header(s)
Power related:
- 2 x 24-pin Main Power connector
- 4 x 8-pin +12V Power connector
- 1 x 8-pin PCIe Power connector
Storage related:
- 2 x M.2 slots (Key M)
- 3 x SlimSAS slots
- 4 x SATA 6Gb/s ports
USB:
- 1 x USB 3.2 Gen 2x2 connector (support(s) USB Type-C )
- 1 x USB 3.2 Gen 1 header(s) support(s) 2 additional USB 3.2 Gen 1 ports
- 2 x USB 2.0 header(s) support(s) 4 additional USB 2.0 ports
Miscellaneous:
- 1 x BMC header
- 1 x COM Port header
- 1 x FlexKey button
- 1 x Front Panel Audio header (AAFP)
- 1 x LN2 Mode jumper
- 1 x ReTry button
- 1 x Start button
- 1 x SPI TPM header (14-1pin)
- 1 x 20-3 pin System Panel header with Chassis intrude function
- 1 x Thermal Sensor header
- 1 x VROC Key header
- BIOS:512 Mb Flash ROM, UEFI AMI BIOS
- Manageability: WOL by PME, PXE (UEFI mode)
Accessories:
- Cables:2 x SATA 6Gb/s cables
Miscellaneous:
- 1 x Q-connector
- 1 x M.2 Rubber Package(s)
- 1 x M.2 backplate Rubber Package(s)
- 1 x CPU guard for LGA 4677 E1A
- 1 x CPU guard for LGA 4677 E1B
Documentation:
- 1 x ACC Express Activation Key Card
- 1 x User guide
- Operating System:
- Windows 11, Windows 10 64-bit
Form Factor:
- CEB Form Factor:12 inch x 10.5 inch (30.5 cm x 26.67 cm)
